Dawnice Battery
15kWh Battery Home Energy Storage
Model HZEB-LCT-15 | 51.2V 300Ah Wall-Mounted Lithium Battery
HZEB-LCT-15 15kWh Specifications
- Product Name: Dawnice 48V 300Ah 15kWh lithium battery
- Model Number: HZEB-LCT-15
- Warranty: 10 years
- Anode Material: LFP
- Application: Solar Power System Home
- ODM & OEM: Supported
- Certification: UN38.3, MSDS, IEC62619, CE, UL1973, UL2054 (Cell)
- Life Cycling: 6000 cycles @ 0.5C; 80% DOD
- Scalable (Parallel function): Yes, maximum 16 pack
- Nominal Voltage: 51.2V (44.8V – 57.6V)
Product Overview
15kWh LiFePO4 Battery Features
- Enhanced Capacity & Power Output: Delivers up to 15kWh of energy per unit for robust performance.
- Expandable with Parallel Support: Can be connected in parallel with up to 16 units for scalable energy storage.
- Premium Quality: Built with A-grade lithium battery cells for superior reliability and performance.
- Versatile Applications: Ideal for Off-Grid and Hybrid Solar Storage Systems, as well as industrial projects.
- Advanced BMS with RS485/CAN Communication: Provides 100% protection and compatibility with most inverters.
Dawnice HZEB-LCT-15 Technical Specifications
| Model | HZEB-LCT-15 |
|---|---|
| Nominal Voltage | 51.2V |
| Cell Model/Configuration | 3.2V/314Ah/16S1P |
| Capacity (Ah) | 314Ah |
| Rated Energy (kWh) | 16.08kWh |
| Max Charge/Discharge Current (A) | 150A |
| Voltage Range (V) | 44.8-57.6V |
| Scalability | Up to 15 parallel |
| Communication | CAN/RS485 |
| Cycle Life | ≥8000 cycles @ 25°C, 80% DOD |
| Design Life | ≥15 years @ 25°C |
| Weight (kg) | 128kg |
|---|---|
| Dimension (L/W/H) mm | 460×288×800mm |
| Installation Mode | Wall Mounted |
| IP Grade | IP54 |
| Safety (Pack) | UN38.3/MSDS/EC626/19(B)/CE-EMC |
|---|---|
| Safety (Cell) | UN38.3/MSDS/EC26/19-CE/UL1973/UL2054 |
| Protection | BMS |
| Operating Temperature | Charge 0°C-50°C; Discharge -10°C-50°C |
|---|---|
| Altitude (m) | ≤2000m |
| Humidity | >90% (Non-condensing) |
